Shelly Plus 0-10V Light Dimmer WiFi/Bluetooth
Shelly Plus 0-10V Light Dimmer WiFi/Bluetooth
Wireless connectivity and convenient control
Thanks to wireless WiFi connection and integrated Bluetooth module, they offer flexible control and easy integration with other devices.
Brightness tailored to your needs
Set lighting according to your needs with the option of voice control for a comfortable home.
Intelligent schedules and energy savings
Intelligent schedules automatically adjust lighting to the daily cycle and help save energy.
Shelly Plus 0-10V Light Dimmer is the perfect solution for smart lighting offering versatility and ease of use. Simply connect it to your home WiFi network and enjoy convenient lighting control without the need for additional hubs. With the integrated Bluetooth module, the device can be connected to other Shelly products or used as a central point for home control. By setting intelligent schedules, lighting automatically adapts to day and night cycles, enhancing user comfort and saving energy.
The device allows adjusting room brightness to current needs. Using voice assistants like Alexa or Home Assistant, you can easily control lighting with a simple verbal command. Without the need for additional hubs, just use the Shelly Smart Control app or other compatible platforms.
The dimmer also offers the ability to create custom lighting scenarios and schedules, making the device tailored to your lifestyle. Shelly Plus 0-10V Dimmer is thus an ideal solution for modern and smart home environments.
Specifications
- Manufacturer:
- Shelly
- Model
- 0-10V
- Power Supply Voltage
- 110 V to 240 V AC
- Power Consumption
- up to 1.2 W
- Neutral Wire
- not required
- Control Type
- Voltage 0 - 10 V (sinking)
- Maximum Control Voltage
- 10 V DC
- Maximum Control Current
- 0.35 W
- WiFi Protocol
- 802.11 b/g/n
- WiFi Range
- Up to 30 m indoors and up to 50 m outdoors (depends on local conditions)
- Maximum RF Power
- up to 20 dBm
- RF Bandwidth
- 2401 MHz to 2495 MHz
- Bluetooth Standard
- 4.2
- Bluetooth Range
- Up to 10 m indoors and up to 30 m outdoors (depends on local conditions)
- Maximum RF Power
- up to 4 dBm
- RF Band
- 2400 MHz to 2483.5 MHz
- Chip
- ESP32 4 MB Flash
- Number of Schedules
- 20
- MQTT
- yes
- Scripts
- yes
- Operating Temperature
- -20 °C to 40 °C
- Operating Humidity
- 30% to 70% relative humidity
- Maximum Elevation
- 2000 m
- Maximum Tightening Torque of Screw Connections
- 0.4 Nm
- Maximum Cable Cross-section
- from 0.2 mm² to 2.5 mm² / from 24 AWG to 14 AWG
- Length of Stripped Wire
- from 5 mm to 6 mm
- Installation
- terminal block
- Material
- plastic
- Dimensions
- 42 × 37 × 17 mm
- Weight
- 17 g
